65Tap Pulse Shaping Filter using VHDL

RTL Code

library ieee;
use ieee.std_logic_1164.all;
use ieee.std_logic_arith.all;
use ieee.std_logic_signed.all;
library work;
use work.mypackage.all;

entity psf65T is
port(
	nrst : in std_logic;
	clk : in std_logic;
	PSFin: in std_logic_vector(9 downto 0);
	PSFout : out std_logic_vector(9 downto 0));
end entity;

architecture arch of psf65T is

signal reg : std_10b_array(64 downto 0);
signal sum11b : std_11b_array(31 downto 0);
signal sum21b : std_21b_array(31 downto 0);
signal sum22b : std_22b_array(15 downto 0);
signal sum23b : std_23b_array(7 downto 0);
signal sum24b : std_24b_array(3 downto 0);
signal sum25b : std_25b_array(1 downto 0);
signal sum26b : std_logic_vector(25 downto 0);
signal sum27b : std_logic_vector(26 downto 0);
signal center : std_logic_vector(19 downto 0);

constant hvector : std_10b_array(0 to 32) := std_10b_array'(
	conv_std_logic_vector(4, 10),
	conv_std_logic_vector(3, 10),
	conv_std_logic_vector(2, 10),
	conv_std_logic_vector(-1, 10),
	conv_std_logic_vector(-3, 10),
	conv_std_logic_vector(-6, 10),
	conv_std_logic_vector(-8, 10),
	conv_std_logic_vector(-8, 10),
	conv_std_logic_vector(-7, 10),
	conv_std_logic_vector(-4, 10),
	conv_std_logic_vector(1, 10),
	conv_std_logic_vector(7, 10),
	conv_std_logic_vector(12, 10),
	conv_std_logic_vector(16, 10),
	conv_std_logic_vector(17, 10),
	conv_std_logic_vector(15, 10),
	conv_std_logic_vector(10, 10),
	conv_std_logic_vector(1, 10),
	conv_std_logic_vector(-10, 10),
	conv_std_logic_vector(-21, 10),
	conv_std_logic_vector(-31, 10),
	conv_std_logic_vector(-36, 10),
	conv_std_logic_vector(-36, 10),
	conv_std_logic_vector(-28, 10),

	conv_std_logic_vector(-12, 10),
	conv_std_logic_vector(13, 10),
	conv_std_logic_vector(43, 10),
	conv_std_logic_vector(77, 10),
	conv_std_logic_vector(113, 10),
	conv_std_logic_vector(145, 10),
	conv_std_logic_vector(171, 10),
	conv_std_logic_vector(188, 10),
	conv_std_logic_vector(193, 10));

begin

process(nrst, clk)
begin
if nrst = '0' then
	reg <= (others => "0000000000");
	PSFout <= (others => '0');
elsif clk'event and clk = '1' then
	reg(64 downto 1) <= reg(63 downto 0);
	reg(0) <= PSFin;
	PSFout <= rndsat(sum27b, 9, 8);

end if;
end process;


stage0 : for i in 0 to 31 generate
	sum11b(i) <= sxt(reg(i), 11) + sxt(reg(64-i), 11);
end generate;


stage1 : for i in 0 to 31 generate
	sum21b(i) <= sum11b(i) * hvector(i);
end generate;


center <= reg(32) * hvector(32);
stage2 : for i in 0 to 15 generate
	sum22b(i) <= sxt(sum21b(2 * i), 22) + sxt(sum21b(2*i+1), 22);
end generate;


stage3 : for i in 0 to 7 generate
sum23b(i) <= sxt(sum22b(2 * i), 23) + sxt(sum22b(2*i+1), 23);
end generate;


stage4 : for i in 0 to 3 generate
	sum24b(i) <= sxt(sum23b(2 * i), 24) + sxt(sum23b(2*i+1), 24);
end generate;


stage5 : for i in 0 to 1 generate
	sum25b(i) <= sxt(sum24b(2 * i), 25) + sxt(sum24b(2*i+1), 25);
end generate;


sum26b <= sxt(sum25b(0), 26) + sxt(sum25b(1), 26);
sum27b <= sxt(sum26b, 27) + sxt(center, 27);


end arch;

---

TestBench Code

library ieee;
use ieee.std_logic_1164.all;
use ieee.std_logic_arith.all;
use ieee.std_logic_misc.all;

entity tb_psf65T is
end tb_psf65T;

architecture behavior of tb_psf65T is

component psf17T is
port(
	nrst : in std_logic;
	clk : in std_logic;
	PSFin: in std_logic_vector(9 downto 0);
	PSFout : out std_logic_vector(9 downto 0));
end component;

component psf65T is
port(
	nrst : in std_logic;
	clk : in std_logic;
	PSFin: in std_logic_vector(9 downto 0);
	PSFout : out std_logic_vector(9 downto 0));
end component;

signal nrst, clk : std_logic;
signal impin_65T, impout_65T : std_logic_vector(9 downto 0);
signal impin_17T, impout_17T : std_logic_vector(9 downto 0);

begin
ipsf65T : psf65T port map(
	nrst => nrst,
	clk => clk,
	PSFin => impin_65T,
	PSFout => impout_65T);


inewpsf17T : psf17T port map(
	nrst => nrst,
	clk => clk,
	PSFin => impin_17T,
	PSFout => impout_17T);

clkp : process
begin
	clk <= '1';
	wait for 20 ns;
	clk <= '0';
	wait for 20 ns;
end process;


nrstp : process
begin
	nrst <= '0';
	wait for 100 ns;
	nrst <= '1';
	wait;
end process;


iimp_for_65T : process
begin
	impin_65T <= "0000000000";
	wait for 140 ns;
	impin_65T <= "0111111111";
	wait for 40 ns;
	impin_65T <= "0000000000";
	wait;
end process;


iimp_for_17T : process
begin
	impin_17T <= "0000000000";
	wait for 140 ns;
	impin_17T <= "0111111111";
	wait for 40 ns;
	impin_17T <= "0000000000";
	wait;
end process;

end behavior;

---

Wave Capture
